| Brand Name: | ABB |
| Model Number: | M2QA QABP QAEJ; MQAEJ M2QA |
The M2BAF series is a new product launched by ABB Motors in 2021, exclusively available in the Chinese market. Its standard design voltage is 380V/50Hz, which is closer to the Chinese market. It has a long design service life and is suitable for long-term continuous operation. Obtain a stable mechanical structure through finite element structural optimization design. The design follows IEC international standards and Chinese GB standards, with efficiency reaching IE2 and IE3 energy efficiency levels.
The M2BAF series motors are mainly designed for OEM customers in applications such as fans and water pumps, and are suitable for many industries such as water treatment, HVAC, food and beverage. The excellent quality of M2BAF provides customers with value-added space.
| power | speed | model | number pole | order installation method B3 |
order installation method B5 |
full load | 3/4 load | 1/2 load | Power Factor |
| CENELEC-design | |||||||||
| 0.18 | 900 | M2BA71MA | 6 | 3GBA073211-A_B | 3GBA073211-B_B | 63.7 | 63.8 | 59.0 | 0.71 |
| 0.25 | 895 | M2BA71MB | 6 | 3GBA073212-A_B | 3GBA073212-B_B | 67.2 | 67.2 | 62.6 | 0.69 |
| 0.37 | 915 | M2BA80MA | 6 | 3GBA083211-A_B | 3GBA083211-B_B | 71.0 | 71.1 | 67.0 | 0.69 |
| 0.55 | 920 | M2BA80MB | 6 | 3GBA083212-A_B | 3GBA083212-B_B | 73.9 | 75.0 | 72.8 | 0.71 |
| 0.75 | 960 | M2BA90SLC | 6 | 3GBA093213-A_B | 3GBA093213-B_B | 78.7 | 77.3 | 72.5 | 0.58 |
| 1.1 | 930 | M2BA90SLE | 6 | 3GBA093214-A_B | 3GBA093214-B_B | 78.2 | 78.6 | 76.4 | 0.66 |
| 1.5 | 950 | M2BA100L | 6 | 3GBA103212-A_B | 3GBA103212-B_B | 82.2 | 82.9 | 81.6 | 0.69 |
| 2.2 | 950 | M2BA112MB | 6 | 3GBA113212-A_B | 3GBA113212-B_B | 82.5 | 83.8 | 81.7 | 0.69 |
| 3 | 975 | M2BA132SMB | 6 | 3GBA133211-A_B | 3GBA133211-B_B | 85.3 | 84.5 | 81.3 | 0.63 |
| 4 | 960 | M2BA132SMB | 6 | 3GBA133212-A_B | 3GBA133212-B_B | 84.9 | 85.3 | 83.9 | 0.68 |
| 5.5 | 965 | M2BA132SMF | 6 | 3GBA133214-A_B | 3GBA133214-B_B | 86.1 | 86.6 | 85.5 | 0.71 |
| 7.5 | 971 | M2BA160MLA | 6 | 3GBA163043-A_G | 3GBA163043-B_G | 87.6 | 89.1 | 89.0 | 0.79 |
| 11 | 970 | M2BA160MLB | 6 | 3GBA163044-A_G | 3GBA163044-B_G | 88.7 | 90.1 | 89.9 | 0.79 |
| 15 | 971 | M2BA180MLA | 6 | 3GBA183042-A_G | 3GBA183042-B_G | 89.7 | 90.8 | 90.5 | 0.76 |
| 18.5 | 975 | M2BA200MLA | 6 | 3GBA203043-A_G | 3GBA203043-B_G | 90.7 | 92.0 | 91.9 | 0.79 |
| 22 | 974 | M2BA200MLB | 6 | 3GBA203044-A_G | 3GBA203044-B_G | 91.0 | 92.4 | 92.5 | 0.79 |
| 30 | 985 | M2BA225SMA | 6 | 3GBA223042-A_G | 3GBA223042-B_G | 92.2 | 93.1 | 93.1 | 0.83 |
| 37 | 985 | M2BA250SMA | 6 | 3GBA253042-A_G | 3GBA253042-B_G | 92.4 | 93.2 | 93.0 | 0.83 |
| 45 | M2BA280SA | 6 | 3GBA283110-A_L | 3GBA283110-B_L | |||||
| 55 | M2BA280SB | 6 | 3GBA283120-A_L | 3GBA283120-B_L | |||||
| 75 | M2BA315SMA | 6 | 3GBA313210-A_L | 3GBA313210-B_L | |||||
| 90 | M2BA315SMB | 6 | 3GBA313220-A_L | 3GBA313220-B_L | |||||
| 110 | M2BA315SMC | 6 | 3GBA313230-A_L | 3GBA313230-B_L | |||||
| 132 | M2BA315MLA | 6 | 3GBA313410-A_L | 3GBA313410-B_L | |||||
| 160 | M2BA355SMA | 6 | 3GBA353210-A_L | 3GBA353210-B_L | |||||
| 200 | M2BA355SMB | 6 | 3GBA353220-A_L | 3GBA353220-B_L | |||||
| 250 | M2BA355SMC | 6 | 3GBA353230-A_L | 3GBA353230-B_L | |||||
| 45 | 990 | M2BAT280SMA | 6 | 3GBA283210-A_E | 3GBA283210-B_E | 92.8 | 93.0 | 92.1 | 0.84 |
| 55 | 990 | M2BAT280SMB | 6 | 3GBA283220-A_E | 3GBA283220-B_E | 93.3 | 93.5 | 92.9 | 0.84 |
| 75 | 992 | M2BAT315SMA | 6 | 3GBA313210-A_E | 3GBA313210-B_E | 94.0 | 94.0 | 93.0 | 0.81 |
| 90 | 992 | M2BAT315SMB | 6 | 3GBA313220-A_E | 3GBA313220-B_E | 94.3 | 94.4 | 93.6 | 0.83 |
| 110 | 992 | M2BAT315SMC | 6 | 3GBA313230-A_E | 3GBA313230-B_E | 94.7 | 94.8 | 94.2 | 0.83 |
| 132 | 992 | M2BAT315MLA | 6 | 3GBA313410-A_E | 3GBA313410-B_E | 94.9 | 95.0 | 94.4 | 0.83 |
| 160 | 992 | M2BAT355S | 6 | 3GBA353100-A_E | 3GBA353100-B_E | 94.9 | 95.0 | 94.4 | 0.83 |
| ---High output design | |||||||||
| 75 | 990 | M2BAT280SMC | 6 | 3GBA283230-A_E | 3GBA283230-B_E | 93.8 | 93.9 | 93.3 | 0.84 |
| 75 | M2BA280SMC | 6 | 3GBA283230-A_L | 3GBA283230-B_L | |||||
Thanks to their waterproof and IP55 protect feature, these electric motors are suitable for use in wet or dusty environments. This makes them ideal for applications in the marine, mining, and construction industries where water and dust are present.
The ABB M2QA QABP QAEJ, MQAEJ M2QA 3 Phase Electric Motors are also known for their low noise operation. This makes them a great choice for use in residential and commercial buildings where noise pollution is a concern. They are also suitable for use in hospitals, schools, and other sensitive environments where noise levels need to be kept to a minimum.
With a motor power range of 0.06–1119 KW and an AC voltage of 380V, these electric motors are versatile enough to be used in a wide range of applications. Whether you need a motor for a small machine or a large industrial process, there is an ABB M2QA QABP QAEJ, MQAEJ M2QA 3 Phase Electric Motor that can meet your needs.
In addition to the M2QA QABP QAEJ, MQAEJ M2QA 3 Phase Electric Motors, ABB also offers other models such as the ABB M3AA and ABB M2BAX. These models are also designed to provide reliable and efficient performance in a variety of applications.
