| Nominal diameter mm | 20 | 25 | 40 | 50 | 65 | 80 | 100 | 150 | 200 | 250 | 300 | ||
| Diameter of valve seat mm | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 | 125 | 150 | 200 | Contact us | |
| Rated flow coefficient Kv | 6.5 | 10 | 15 | 25 | 40 | 65 | 100 | 150 | 260 | 350 | 540 | ||
| Nominal pressure MPa | 1.6 ； 4.0 ； 6.4 | ||||||||||||
| Travel mm | 10 | 16 | 25 | 30 | 40 | 60 | |||||||
| Flow characteristics | Quick open | ||||||||||||
| Media temperature ℃ | Soft sealing :-40～150(normal temperature ) ； hard sealing:-40～200(normal temperature)； -40～450(medium temperature) | ||||||||||||
| Flange size,type | PN16 according to JB79-59； PN4.0,64 according to JB/T79.2-94 concave | ||||||||||||
| Material of valve body | ZG230-450 ； ZG1Cr18Ni9Ti；ZGOCr18Ni12Mo2Ti | ||||||||||||
| Material of valve seat,valve spool | 1Cr18Ni9 ； 0Cr18Ni12Mo2Ti | ||||||||||||
| Upper cover | General (normal temperature) ； heat sink(medium temperature ) | ||||||||||||
| Components | Handwheel body,air filter regulator ,solenoid valve,feedback device of signal | ||||||||||||
