| Brand Name: | RG |
| Model Number: | ZSHRF |
| MOQ: | 1 set |
| Payment Terms: | T/T |
| Supply Ability: | 1000pcs / month |
ZSHRF pneumatic ball valve Pneumatic rubber fluorine O type ball valve
Pneumatic rubber fluorine O type ball valve is a rotary cutting type ball valve. It consists of cylinder piston type actuators and lining fluorine plastic ball valve in two parts. Because of the valve body cavity and sphere completely lined with fluoroplastic, it has corrosion resistance and impermeability. Can be widely used in chemical, oil, metallurgical, pharmaceutical, electric power and other industrial department, the implementation process of strong corrosive medium such as acid, alkali cut or adjust.
Product features:
1. Corrosion resistance: the valve body cavity and sphere are package 2.5-3 mm thick lining F46, acid, alkali, strong corrosion resistance.
2. Use soft sealing seat, sealed performance is good.
3. Small volume, light weight, simple structure, easy installation and maintenance.
4. The flow resistance is small, large flow capacity.
5. If with the valve positioning, proportional control can be realized.
Technical parameters:
Nominal diameter: DN15-150mm
Nominal pressure: PN1.0-1.6 Mpa
Valve type used to gas gas type or open type
The valve body material: ZG25, CF8 lining F46
Valve core materials: ZG25, CF8 lining F46
Attached parts, pneumatic actuators, gas, air filtration pressure reducer valve positioning, insurance, travel on off valve, valve position transmitter, hand wheel, etc
